Datalogic PM8000

TECHNOLOGY DRIVEN

The PowerScan PM8300 series includes different models able to satisfy all customer's needs; the PM8300 is the basic cordless model; the PM8300-D intermediate model includes a display and 3-key keypad; and the ultimate PM8300-DK model features a display and a full 16-key keyboard. The PM8300-DK model significantly increases the sophistication of interaction with the host system and opens up new potential uses of the scanner, making it suitable for applications that would normally require a more expensive portable data terminal. The BC9180 used in compatibility mode, also includes in one model two different Ethernet connections: Standard Ethernet and Industrial Ethernet protocols such as Ethernet IP and Modbus.

DATALOGIC'S STAR CORDLESS SYSTEM

Narrow band radio communications with Datalogic's STAR Cordless System provides the key to increased productivity and flexibility in the workplace. It offers scalable solutions from simple point-to-point applications to networking capabilities combined with seamless roaming for complex installations.

GOOD-READ FEEDBACK AND SUPERIOR READING PERFORMANCE

The PM8300 readers feature Datalogic's exclusive 3 Green Lights (3GL) for superior good-read feedback. The patented Green Spot directly on the code and dual Good Read LEDs on the top and back of the cap adds increased visibility at any angle. Superior reading performance is enhanced by Datalogic's patented PuzzleSolver's technology for fast and accurate reading of standard, poorly printed and damaged codes.

FEATURES

• Optics available in Standard Range (contact up to 1.0 m / 3.3 ft) and Auto Range (20 cm / 8 in up to 12.5 m / 41.0 ft)
• Available in 3 models: basic, with display and 3-Key keypad, with display and full alphanumeric keypad
• 100% Compatible with Datalogic's STAR Cordless System's
• Radio frequencies available in 433 MHz or 910 MHz
• Point-to-point and multi-point transmission
• Seamless roaming
• Ethernet Connectivity (Standard and Industrial)
• Datalogic 3GL and loud beeper for good read feedback
• User replaceable lithium-ion battery
• Operates over a wide range of temperatures
• Water and Particulate Sealing Rating: IP65 / IP64 (with display)
• Drop resistance to 2.0 m / 6.5 ft
• EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI

INDUSTRY-APPLICATIONS

• Manufacturing /Warehouse
• Retail / POS Check-out
• Transportation and Logistics / Warehouse / Sorting
