99-047A002-1001 - TSC TTP-246M Pro TT Printer [203dpi]

See Our Holiday Hours

Replacement Product is available!

  • TSC TTP-246M Pro TT Printer [203dpi, Ethernet]

    ( SKU: 99-047A002-1101 )

    Prints both
    Thermal Transfer and
    Direct Thermal

    Thermal Transfer and Direct Thermal Industrial Printer, Pro, 203 DPI, 8 Inches Per Second, 3 Ports, USB, Parallel, Serial, Internal Ethernet, Real Time Clock Includes: US Power Cord

TSC TTP-246M Pro TT Printer [203dpi] 99-047A002-1001
TSC TTP-246M Pro TT Printer [203dpi] 99-047A002-1001
TSC TTP-246M Pro TT Printer [203dpi]

TSC TTP-246M Pro TT Printer [203dpi]

SKU: 99-047A002-1001
Weight: 15 lbs.

Printer Type Industrial
Print Technology Thermal Transfer
Interface Serial USB Parallel
dpi (dots per inch) 203dpi
Core Size 1.00 inch
Max Media Width 4.0-4.9 inch
Printer Language TSPL

Product Highlights

Thermal Transfer and Direct Thermal Industrial Printer, Pro, 8 Inches Per Second, 203 DPI, 8MB DRAM, 4MB Flash, USB, Serial, Parallel, TSPL-EZD Language Includes: US Power Cord

Prints both
Thermal Transfer and
Direct Thermal

TTP-246M Pro Series

Durable High Quality Performance

The TTP-246M Pro Series is based on the proven TTP-246M platform with many significant changes.


Pro Series enhancements

The new Pro Series features a separate die-cast aluminium base plate and backplane that includes a metal media supply spindle and sturdy two roller damper. Built specifically for the budget-minded, this new design results in a more durable printer that is suited for your most heavy-duty demand cycles.


Other enhancements include a new motor mount for quieter printing, a gap sensor lock to keep the label sensor from shifting, and a new anti-static ribbon brush. Finally, TSC has added an optional USB Host option for applications that require the use of either a USB scanner or keyboard.


Superb resolution, great warranty

There are two models available with the TTP-246M Pro Series. The TTP-246M Pro prints at 203 dpi at speeds up to eight inches per second, and TTP-344M Pro offers 300-dpi resolution at speeds up to six inches per second. All TSC printers feature a standard two-year limited warranty.


Loaded with standard features

The TTP-246M Pro Series printers are loaded with standard features including support for 600 meter ribbons, 8.2" OD media rolls, a large 6-button LCD display, built-in USB 2.0, parallel and serial interfaces. An internal Ethernet networking for simple integration, GPIO port or a USB Host port is available as an option.


Memory to spare

The Pro Series offers memory, including 8 MB DRAM and 4 MB FLASH, which provides easy storage of fonts, international character sets and graphics. The Pro Series also includes a secure digital (SD) FLASH memory card reader for inexpensively adding up to 4 GB of memory as an option.


Powerful TSPL-EZ Printer Programming Language

TSC ships TSPL-EZ  firmware in all its printers. TSPL-EZ supports three different printer languages including TSC printer language, TPLE (Translation Printer Language Eltron ), and TPLZ (Translation Printer Language Zebra ). TSPL-EZ features internal scalable True Type fonts, and a BASIC interpreter with file manager for creating powerful printer interface applications with multiple type of hosts.

Key Features

  • Heavy duty die-cast aluminum design

  • 600-meter ribbon supply

  • Large LCD display with 6-button menus

  • USB 2.0, serial and parallel connectivity are standard

  • Available in 203 and 300 dpi resolution versions

  • Up to 203 mm (8") per sec. print speed

  • 32-bit RISC processor

  • TSPL-EZ firmware for plug-n-play ease

  • Powerful basic programming tools

  • Options include: Ethernet; USB host for use with keyboards and scanners; peel, present & rewind; cutter


  • Industrial-duty Printing

  • Healthcare Patient Safety

  • Compliance Labeling

  • Work in Process

  • Order Fulfillment

  • Distribution

  • Shipping/ Receiving

  • Ticketing

  • Electronics & Jewelry Labeling
