Laird TRABT1500 Laird Antenex VHF Omni Antenna
| Part Type | Antenna |
| Interface | Coaxial |
| Environment | Indoor/Outdoor |
| Frequency Ranges | VHF Antennas (132-175 MHz) |
Product Highlights
Laird TRABT1500 Laird Antenex VHF Omni Antenna 150-168 Mhz - 3/4 Inch NMO. Ground Plane Required. Soup Can Style Phantom. Black MNF# TRABT1500We also offer Thru-Hole NMO Mounts and Magnetic NMO Mounts. Contact us for to discuss your project.
Spec. Sheet
Laird Low Profile/Phantom Antennas
Introducing Laird's Low Profile/Phantom Antennas! Revolutionizing communication with their whipless design, these antennas offer omni-directional radiation and vertical polarization, ensuring frequency agility and superior performance in various applications. Their low visibility and angle radiation pattern make them ideal for public safety, transportation, commercial, industrial communication, and IoT. With easy installation options and UV-treated radome for durability, Laird antennas are the pinnacle of efficiency and reliability in modern communication systems.
Note: Field tuning is REQUIRED for this antenna, see tuning guide below: This unit is a Black 'Phantom' style / Stealth VHF Omni-directional antenna with standard 3/4 inch NMO-mobile mount operating at 150-168 Mhz range. This antenna is a 'Soup Can' style and offers a powerful punch with up to 3 dBi of gain. Please note that this model REQUIRES mounting on metallic ground plane for best performance. The Phantom series offers ultra-rugged ABS construction which is virtually indestructible and has a proven track record for holding up in the field for many years in any conditions. 3/4 inch NMO Cable kits and mounting hardware or magnetic mounts for this antenna can be purchased separately. *This Antenna Requires a NMO Mount. We offer Thru-Hole NMO Mounts and Magnetic NMO Mounts. Contact us for to discuss your project.
Specifications
| SKU | TRABT1500 |
|---|---|
| Manufacturer Part Number | TRABT1500 |
| Manufacturer | Laird |
| Antenna Category | VHF (132-220 MHz) |
| Working Frequency | 150-168Mhz |
| Gain | Unity |
| Antenna Style | Phantom Low Profile |
| Polarity | Dual Polarity |
| Bands | Single |
| SISO or MIMO | SISO |
| Directional or Omni | Omnidirectional |
| Impedance | 50 ohms |
| Max Input Power (W) | 60 Watts |
| Horizontal/Azimuth Beamwidth | 360 |
| Height/Length (inches) | 3.3 Inches |
| Height/Length (mm) | 83.8 mm |
| Thickness/Diameter (inches) | 3.25 |
| Thickness/Diameter (mm) | 82.6 |
| Weight (lbs) | 0.35 |
| Weight (grams) | 159.1 |
| Material | ABS Plastic |
| Operating Temp (celsius) | (-40 C) to 85 C |
| Mount Style | NMO-mobile mount |
| Color | Black |
| Connector Type | Connector - Bottom |
| Connector 1 | NMO |
| Includes | O-Ring |
| OK for Outdoor Use | Yes |
| Vehicular | Yes |
| Ground Plane Required | Yes |
| Product Condition | New |
