Laird TRAT1500 Phantom Omni Antenna
| Part Type | Antenna |
| Interface | Coaxial |
| Environment | Indoor/Outdoor |
| Frequency Ranges | VHF Antennas (132-175 MHz) |
| Minimum Order Quantity | 10 |
Product Highlights
Laird TRAT1500 Phantom Omni Antenna- 150-168Mhz - NMO - Ground Plane Reqd VHF Low Profile Antenna White MNF# TRAT1500We also offer Thru-Hole NMO Mounts and Magnetic NMO Mounts. Contact us for to discuss your project.
Spec. Sheet
Laird Low Profile/Phantom Antennas
Introducing Laird's Low Profile/Phantom Antennas! Revolutionizing communication with their whipless design, these antennas offer omni-directional radiation and vertical polarization, ensuring frequency agility and superior performance in various applications. Their low visibility and angle radiation pattern make them ideal for public safety, transportation, commercial, industrial communication, and IoT. With easy installation options and UV-treated radome for durability, Laird antennas are the pinnacle of efficiency and reliability in modern communication systems.
Note: Field tuning is REQUIRED for this antenna, see tuning guide below. This unit is a White 'Phantom' style / Stealth VHF Omni-directional antenna with NMO-mobile mount operating at 150-168Mhz range. This antenna offers a powerful punch with up to 3 dBi of gain. Please note that this model REQUIRES mounting on metallic ground plane for best performance. The Phantom series offers ultra-rugged ABS construction which is virtually indestructible, and has a proven track record for holding up in the field for many years in any conditions. Cable kits and mounting hardware for this antenna can be purchased separately. *This Antenna Requires a NMO Mount. Please click here to find all Thru-Hole NMO mounts or Magnetic NMO Mounts we carry. ***This item is subject to an MOQ of 10 pcs***
Specifications
| SKU | TRAT1500 |
|---|---|
| Manufacturer Part Number | TRAT1500 |
| Manufacturer | Laird |
| Antenna Category | VHF (132-220 MHz) |
| Working Frequency | 150-168Mhz |
| Gain | Unity |
| Antenna Style | Phantom Low Profile |
| Polarity | Vertical |
| Bands | Single |
| SISO or MIMO | SISO |
| Directional or Omni | Omnidirectional |
| Impedance | 50 ohms |
| Max Input Power (W) | 60 Watts |
| Horizontal/Azimuth Beamwidth | 360 |
| Vertical/Elevation Beamwidth | 120 |
| Height/Length (inches) | 3.3 Inches |
| Height/Length (mm) | 83.8 mm |
| Width (inches) | 3.25 |
| Width (mm) | 82.6 |
| Weight (lbs) | 0.35 |
| Weight (grams) | 159.1 |
| Operating Temp (celsius) | (-40 C) to 85 C |
| Mount Style | NMO-mobile mount |
| Color | White |
| Connector Type | Connector - Bottom |
| Connector 1 | NMO |
| Includes | O-Ring |
| OK for Outdoor Use | Yes |
| Vehicular | Yes |
| Ground Plane Required | Yes |
| Product Condition | New |
